XC948 Wheel Loader

The Benchmark in Comfort, Reliability, Durability and Efficiency in its Class.

Quick Specs

Rated Op Load

4000 kg

Op Weight

14500 kg

Horsepower

190 HP

Dump Height

2810 mm

The XCMG XC948 wheel loader is a new generation of loader. XCMG makes full use of its international R&D platform to integrate global technology and produce completely independent designs.

As a result, the XC948 front end loader is uniquely comfortable, durable, reliable and efficient – as well as being simple to maintain. With worldwide renown for its performance and value for money, the XC948 is the ideal solution for customers seeking a versatile 14 tonne loader solution for any application or industry.

Equipped with a Tier 3 emission Cummins QSB6.7 engine, automatic 4BP 190 torque converter, XCMG high performance wet axle and full hydraulic wet brake system, the entire machine offers significant reliability, efficiency, comfort and control.

MACHINE SPECIFICATIONS

Key Performance Specs

Operating Weight: 14500 kg (approx)
Engine: Cummins QSB 6.7
Power: 142kW / 190HP
Rated Operating Load: 4000 kg
Dump Height: 2810 mm
Dump Distance: 1082 mm
Wheel Base: 3050 mm
Wheel Track: 2020 mm
Minimum Ground Clearance: 410 mm
Length: 7882 mm
Height: 3405 mm
Width: 2550 mm

Additional Specs

Dumping Angle: 45 Degrees
Max Breakout Force: 130 kN
Max Traction: 135 kN
Turning Radius: 5200 mm
Lift Time of Boom: 4.5 Seconds
Total Hyd Cycle Time: 9.5 Seconds
Tipping Load (Max Steering): 9000 kg
Tipping Load (Straight State): 11000 kg
Speed (1/2/3/4): 7/13/24/38
Rotate Speed: 2200 RPM
Bucket: 2.4m3

PERFORMANCE & FEATURES

HIGH RELIABILITY

  • Cummins QSB6.7 engine provides required power for complex working conditions.
  • Automatic 4BP 190 torque converter transmission reduces shifting impact.
  • XCMG wet axle meets high working load requirements.
  • Full hydraulic wet brake system is highly reliable and maintenance-free.
  • Extra heavy load frame design to extend machine life and performance.
  • Wear resistant and impact resistant high strength steel plate for bucket material.

XCMG-948-Wheel-Loader-Front-End-4tonne-6

XCMG-948-Wheel-Loader-Front-End-4tonne-1

INTELLIGENT

  • Heat management system with large radiator and low speed fan ensures maximum performance.
  • Fan has automatic reversal function for self-cleaning in high dust environments.
  • Quantitative hydraulic system provides on-demand distribution of fuel supply during steering and work unit operation.
  • Command-based controls makes the operator’s work easier and more enjoyable.

COMFORTABLE OPERATION

  • Spacious and ergonomic cab with excellent visibility.
  • FOPS/ROPS cab with heat and air conditioning provides air flow through multiple vents.
  • Well sealed and insulated cab to provide a dust proof environment.
  • All switches are conveniently placed and controls are highly ergonomic.
  • Digital gauges in the cab monitor and display the loader’s vital functions.
  • Suspension seat with excellent lumbar support minimises operator fatigue or discomfort.
  • Integrated F-N-R electronic lever shifting function offers precise control and easy operation.

XC948-Wheel-Loader-Controls

XC948-Wheel-Loader-3

EXCELLENT SAFETY

  • Complies with ISO 5006 operator vision field standards.
  • Complies with ISO 3449, 3471, 3164 ROPS/FOPS cab standards.
  • Complies with ISO 2867, 2860 ladders, passageways, operation platform and exit/access standards.
  • Complies with ISO 10533, 10570 lifting arm bracket and hinged lock device standards.
  • Flame retardant material applied to cab interiors and fire extinguisher equipped.

EASY MAINTENANCE

  • New digital combination meter shows the vehicle running status and various other info at a glance.
  • Side-turn cab and large angle side door openings offer easy access to engine and componentry for easy service.
  • Single row of large tone radiators and an upturned back cover.
  • Centred electrical fuse box for effortless check-ups and high reliability.
  • Remote centred lubrication, drainage pressure testing.

XC948-Wheel-Loader-Engine

IMAGE GALLERY

  • XC948-Wheel-Loader-1
  • XC948-Wheel-Loader-3
  • XC948-Wheel-Loader-Controls
  • XC948-Wheel-Loader-Maintenance
  • XC948-Wheel-Loader-Engine
  • XCMG-948-Wheel-Loader-Front-End-4tonne-6
  • XCMG-948-Wheel-Loader-Front-End-4tonne-5
  • XCMG-948-Wheel-Loader-Front-End-4tonne-4
  • XCMG-948-Wheel-Loader-Front-End-4tonne-3
  • XCMG-948-Wheel-Loader-Front-End-4tonne-2
  • XCMG-948-Wheel-Loader-Front-End-4tonne-1
